Goulds e-GS High Capacity Submersible Pump

Pump End

The e-SV pump is a non-self priming vertical multistage pump coupled to a standard motor.

The liquid end, located between the upper cover and the pump casing, is held in place by tie rods. The pump casing is available with different configurations and connection types.

• Delivery: up to 600 GPM
• Head: up to 1200 feet
• Temperature of pumped liquid: -20ºF to 250ºF (-30ºC to 120ºC) standard version
• Maximum operating pressure – with oval flanges: 230 PSI (15 bar) – with round flanges or Victaulic: 360 PSI (25 bar) – SV33, 46: 230, 360 or 575 PSI (16, 25 or 40 bar)* – SV 66, 92: 230 or 360 PSI (16 or 25 bar)*
• Direction of rotation: clockwise looking at the pump from the top down (marked with an arrow on the adapter and on the coupling).

Motor

• Standard NEMA TC Frame motors in open drip proof or totally enclosed fan cooled.
• 3500 RPM nominal
• Standard voltage:
• Single phase version: 115-208/230 V, 60 Hz up to 3 HP or 208-230 V for 5 HP
• Three phase version, 2 pole: 208-230/460 V, 60 Hz up 75 HP

* Based on pump staging
